The XC9267/68 is a synchronous step-down DC/ DC with P-Ch High Side Switch to ensure low voltage operation with 100% max duty ratio. It can operate from 3.0V~36.0V and deliver loads up to 600mA making it an ideal replacement for inefficient Linear Regulators used in many industrial applications.

Available in the ultra-small USP-6C package, measuring only 2.0 x 1.8 x 0.6mm an extremely small DC/DC circuit can be implemented with a minimal number of external components.

Designed for very high efficiencies at low output loads, with low quiescent current and automatic PFM/PWM mode.  The XC9267/68 also works with Low ESR ceramic capacitors and comes with a choice of two switching frequencies, adjustable soft start and a power good output.

The XC9267/68 includes a fold-back type current limit circuit and the IC will automatically resume normal operation as soon as the over-current condition disappears.
