XBS504V1AR-G Images
- Manufacturer: Torex Semiconductor
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: DO-221BA, SMB Flat Leads Exposed Pad
- Description: SCHOTTKY BARRIER DIODE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
XBS504V1AR-G Specifications:
- Manufacturer Product Number: XBS504V1AR-G
- Mfr: Torex Semiconductor Ltd
- Detailed Description: SCHOTTKY BARRIER DIODE
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Tape & Reel (TR)
- Series: -
- Part Status: Obsolete
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 40 V
- Current - Average Rectified (Io): 5A
- Voltage - Forward (Vf) (Max) @ If: 560 mV @ 5 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): -
- Current - Reverse Leakage @ Vr: 100 µA @ 40 V
- Capacitance @ Vr, F: -
- Mounting Type: Surface Mount
- Package / Case: DO-221BA, SMB Flat Leads Exposed Pad
- Operating Temperature - Junction: 150°C
- XBS504V1AR-G Torex, SCHOTTKY BARRIER DIODE, Discrete Semiconductor Products~Diodes - Rectifiers - Single
XBS504V1AR-G, Torex authentic parts in stock from Torex authorized distributors, order today, can ship immediately.
